A ruler can also be used to quickly measure short distances. Then trace the edge of the ruler with a pencil or technical pen to draw a straight line on the paper. To do this, place the ruler at specific points on a drawing or surface. Rulers: Practical aids for drawing and measuringįirst and foremost, rulers are a practical tool for drawing straight lines. You can also find our products in practical sets with additional drawing tools such as a compass, pencil and more.
In Shape Layer Properties setting Label, Color, Transparency for the selected shape, also Show shape labels parameter can be enabled/disabled.In this category, you will find a comprehensive selection of sturdy set squares and rulers in a variety of designs and sizes for all sorts of applications:įurthermore, we also offer durable set squares and other practical working tools for use in school. To set properties for layer select Properties command in the layer context menu. To edit an attribute, double-click on the corresponding field with the left mouse button. To add an attribute for shape, click Add Attribute button on the Properties pane. You can set Label, Description, and Layer name in the Properties dialog window. To select a shape click on the corresponding polygon/polyline/point in the project window. The shape properties are specified on the Properties tab available from View > Panes > Properties. The properties displayed on the Properties tab are for the selected shape. The following drawing tools are available in Agisoft Viewer: To create a vector layer use New Vector Layer button on the Layers pane or the corresponding option in File menu. Volume measurement and profile creation are also available from the polyline/polygon context menu.ĭrawing tools are available only in a vector layer, therefore to start drawing you need to either add a new vector layer or import a shape layer for the project. Volume is calculated Above set level and Below set level, also Total volume value is calculated according to the following formula: Total volume = V olume above - absolute value of the Volume below
#Sketch ruler tool update#
Update button should be pressed for the Volume to be re-calculated against the set level. The Level is set by the user in the corresponding box. Volume measured against custom level plane allows tracing volume changes for the same area in the course of time. Best fit and mean level planes are calculated based on the altitudes of the bounding polygon vertices. Options include Best fit plane, Mean level plane, and Custom level plane. In Volume section, it is possible to choose a preferable Base plane for volume calculation. Perimeter, 2D (Altitude value is not used for calculation).Longitude, Latitude, and Altitude for the vertices of the bounding area.In Boundary section of the Measure Volume window the following information for the bounding area is available: The Measure Volume pop-up window will appear as shown on the image below. To automatically close the polygon click the right mouse button (or press Esc). Start drawing by clicking the left mouse button to create the first point of the polygon, then draw the bounding area as demonstrated in the image below. Select Measure Volume tool on the Toolbar and draw a polyline to indicate the bounding area. To measure a volume a bounding area should be set first. The range of supported formats includes vector formats: KML, SHP, DXF and raster formats: JPEG, JPEG 2000, PNG, TIFF, BMP, OpenEXR, TARGA. The profile can be saved by pressing Save button (as highlighted on the image below). The profile will appear in the Measure Profile pop-up window as shown in the animation below. Click the left mouse button to start drawing and the right mouse button (or press Esc) to end the polyline. To build a profile select Calculate Profile tool on the Toolbar and draw a polyline to set the profile guideline. The measured distance will appear in the rectangle next to the second of the endpoints. To measure a distance on the model select Ruler tool on the toolbar and choose the distance you'd like to measure by left-clicking on two endpoints. The following measure tools are available i n Agisoft Viewer: Measurements in Agisoft Viewer are made in meters.
All tools are available on the Toolbar or from the Tools menu: You can measure distances on the model and also check the surface area and volume of the reconstructed 3D model.
There are measure and drawing tools available in Agisoft Viewer. Agisoft Viewer Measure and Drawing tools in Agisoft Viewer
